Cause 1

Cogged Belt

Inspect the belt to see if it is broken, stretched out, or out of place. If the cogged belt is broken or stretched out, replace it.

Cause 2

Drive Belt

Inspect the belt to see if it is broken, stretched out, or out of place. If the drive belt is broken or stretched out, replace it.

Cause 3

Belt

Inspect the belt to see if it is broken, stretched out, or out of place. If the vacuum cleaner belt is broken or stretched out, replace it.

Cause 1

Fan Motor

First, test the power switch for continuity to ensure that the motor is getting power. If the power switch has continuity, ensure that the blower wheel turns freely and is clear of obstructions. If power is getting to the motor, and the motor turns freely, but the motor still won’t run, replace the fan motor.

Cause 2

Drive Motor

First, test the power switch for continuity to ensure that the motor is getting power. If the power switch has continuity, ensure that the blower wheel turns freely and is clear of obstructions. If power is getting to the motor, and the motor turns freely, but the motor still won’t run, replace the motor.

Cause 3

On - Off Switch

To determine if the switch is defective, use a multimeter to test it for continuity. If the on-off switch does not have continuity, replace it.

Cause 1

Brushroll

If too much hair, string, or lint is caught in the brushroll, the brushroll can get stuck. If the brushroll is stuck, it will put too much strain on the belt and may cause the belt to break. Remove the brushroll and clean out any debris from the bearings. After replacing the brushroll, make sure that it turns freely.

Cause 1

Vacuum Hose

Remove the hose from the vacuum cleaner, stretch out the hose so that it is straight, shine a bright flashlight into one end of the hose, and look through the opposite end of the hose. If the flashlight beam is not visible from the other end of the vacuum hose, this indicates that the vacuum hose is clogged or obstructed.

Cause 2

Exhaust Filter

The exhaust filter traps particles as the air travels through the vacuum cleaner. If the filter is clogged, the vacuum cleaner will not have proper suction. If your vacuum filter is clogged, refer to your owner’s manual for cleaning instructions.

Cause 3

Air Filter

The air filter traps particles as the air travels through the vacuum cleaner. If the filter is clogged, the vacuum cleaner will not have proper suction. If your vacuum filter is clogged, refer to your owner’s manual for cleaning instructions.
