REGULATORS AND ACCESSORIES

Regulator and Accessories Parts

Regulator and Accessories Parts

COMPACT HIGH PRESSURE FIRST STAGE REGULATOR # 1

LV2302TR

APPLICATION
Ideal for small and medium size domestic LP-Gas installation requiring no more than 500,000 BTU’s/hour. These regulators are factory set to reduce tank pressure to an intermediate pressure of approximatelty 10 PSIG.

HIGH PRESSURE FIRST STAGE REGULATORS# 2

LV4403SR AND TR SERIES

APPLICATION
Provide accurate first stage regulation in two-stage bulk tank systems. These regulators handle vaporization of tanks up to 1200 gallons. Reduce tank pressure to an intermediate pressure of 5 to 10 PSIG. Also used to supply high pressure burners for application like industrial furnaces or boilers.

LOW PRESSURE SECOND STAGE REGULATORS # 3

LV4403B SERIES

APPLICATION
Designed to reduce first stage pressure of 5 to 20 PSIG down to burner pressure. Ideal for medium commercial installations, multiple cylinder installations and normal domestic loads.

SECOND STAGE REGULATORS FOR 2 PSIG SYSTEMS # 4

LV4403Y4VI

APPLICATION
Designed to reduce first stage pressure of 10 PSIG down to 2 PSIG. System that reduce that utilize this regulator use smaller than normal piping inside of the building. A special final stage regulator, not the appliance regulator, is required to reduce this intermediate 2 PSIG pressure down to 11’’ w.c.

LOW PRESSURE SECOND STAGE REGULATORS # 5

2503B SERIES

APPLICATION
Designed to reduce first stage pressure of 5 to 20 PSIG down to burner pressure, normally 11’’ w.c. ideal for larger commercial and industrial application, multiple cylinder installation and large domestic systems.

LOW PRESSURE SECOND STAGE TOBACCO BARN REGULATOR # 6

2503G SERIES

APPLICATION
Especially developed for drying barns in the tobacco industry. The 2503G regulator will supply a steady and constant flow of fuel to as many as 12 to 20 burners throughout the barn.

COMPACT TWIN STAGE REGULATORS # 7

LV404B4 SERIES

APPLICATION
This compact two-stage regulator is designed to reduced container pressure down to 11’’ w.c. delivery pressure. It is ideal for “on-site” cylinder applications, mobile homes and average domestic service including small ASME and 100 to 420 pound DOT cylinders.

COMPACT TWIN STAGE REGULATORS # 8

LV404B23 SERIES

APPLICATION
The LV404B23 regulator is designed for small domestic applications with flow requirements up to 200,000 BTU’s/hr. it is ideal for mobile homes, cottages and “on-site” cylinder applications. The LV404B23 can also be used in RV applications if a protective cover is also supplied.

TWIN STAGE AUTOMATIC CHANGEOVER REGULATORS # 9

7523B SERIES

APPLICATION
These combination automatic changeover, two stage regulators are especially suitable for homes, mobile homes, construction and other portable two cylinder installatons. Empty containers may be replaced without interrupting customer’s gas service.

TWO STAGE REGULATOR OUTFITS # 10

5800 SERIES

APPLICATION
These outfits contain the equipment required to provide two-stage regulation

COMPACT REGULATORS # 11

301 AND 302 SERIES

APPLICATION
These compact regulators are designed for smaller outdoor grills and fish cookers.it is intended for use on small portable appliances that use 100,000 BTU’s/hr or less. It may not be used on fixed pipe systems per NFPA 58, 1995 edition.

LOW PRESSURE SINGLE STAGE REGULATORS # 12

2302 SERIES

APPLICATION
A compact, study regulator incorporating many of the quality features found in larger domestic regulations. Ideal for outdoor LP-GAS grills. The regulator reduces cylinder pressure down to burner pressure, normally 11’’ w.c. it is intended for use on small portable appliances that use 100,000 BTU’s/hr. it may not be used on fixed pipe systems per NFPA 58, 1985 edition.

COMPACT TWIN-STAGE REGULATOR ASSEMBLIES # 13

303V SERIES

APPLICATION
This regulator is a combination of the 301 and 302V model. It is intended for use on small portable appliances that use 100,000 BTU’s/hr or less. It may be used on fixed pipe system per NFPA 58, 1985 edition.

COMPACT SINGLE STAGE REGULATOR OUTFIT # 14

PK302A

APPLICATION
This outfit contains all the necessary parts to manifold the model 302V regulator between two cylinders. It is intended for use on small portable appliances that use 100,000 BTU’s/hr or less. It may be used on fixed pipe system per NFPA 58, 1985 edition.

HIGH PRESSURE INDUSTRIAL/COMMERCIAL POUNDS-TO-POUNDS REGULATORS # 15

567F SERIES

APPLICATION
Designed to reduce container pressure down to between 3 and 100 PSIG. Ideal for liquid or vapor service with tar pot heaters, fish cookers, salamander heaters and weed burning torches.

HIGH PRESSURE INDUSTRIAL/COMMERCIAL POUNDS-TO-POUNDS REGULATORS # 16

499 SERIES

APPLICATION
Designed to reduce container pressure down to between 3 and 65 PSIG. Suitable for liquid or vapor service with small to medium sized loads such as roofing. Weed burners and other industrial type application.

HIGH PRESSURE INDUSTRIAL/COMMERCIAL POUNDS-TO-POUNDS REGULATORS # 17

1580M SERIES AND AA1580M SERIES

APPLICATION
Designed to reduce LP-Gas and anhydrous ammonia container pressures to between 3 and 125 PSIG. Precision-built with a multi-million BTU capacity, the 1580M series is perfect for such big, tough jobs as crops dryers, asphalt batch mixing plants, road building “tar wagons”, heat treating and other large industrial and commercial loads.

HIGH PRESSURE/HIGH TEMPERATURE INDUSTRIAL/COMMERCIAL POUNDS-TO-POUNDS REGULATORS # 18

X1584M SERIES

APPLICATION
Designed to reduce LP-Gas container pressure to between 3 and 50 PSIG. Ideal for crop drying, heat treating, asphalt batch mixing and other large industrial and commercial load application utilizing high temperature LP-Gas or high temperature atmosphere under condition up to 300F. Also ideal as a first stage as a first stage regulator in large regulator in large multiple operations.

COPPER PIGTAILS # 19

912 AND 913 SERIES

APPLICATION
Pigtails are available in a variety of connections, sizes and styles. Care should always be taken in selecting the proper pigtail for a particular application.

MANUAL CHANGEOVER MANIFOLDS # 20

1421R

APPLICATION
Provides positive means to close off one service line and open another in two cylinder systems to give uninterrupted service while the empty cylinder is being replaced.

TEE CHECK MADIFOLDS # 21

1350R AND 1450R

APPLICATION
For use in systems that require uninterrupted gas service during cylinder exchange. Especially for cottages, mobile homes and single appliance loads.

MULTIPLE CYLINDER MANIFOLS # 22

1350E AND 1440E

APPLICATION
Use with suitable pigtails to connect multiple cylinders together. Ideal for loads that require more than one cylinder to be service at a time.

LOW PRESSURE TEST SET # 23

2434A SERIES

APPLICATION
This kit provides the equipment necessary for checking regulator delivery pressure (low pressure) at the appliance.

HIGH PRESSURE GAUGE ADAPTER # 24

2962

APPLICATION
The water manometer kit is especially suited for use with low pressure LP-Gas systems. It is ideal for pressure checks downstream of the low pressure regulator and at the appliances.
