G8475R SERIES

APPLICATION

These multivalves are designed for use in single opening ASME containers equipped with 21/2 “M. NPT riser. They can be used with underground ASME containers up to 639 sq. ft. surface area, and above ground ASME containers up to 192 sq. ft. surface area. A surface area. A separate opening is required for liquid withdrawal. The MultiBonnet is standard on this valve.

8593AR

APPLICATION

These Multivalves provide vapor withdrawal and filling of ASME containers. A separate pressure relief is required in addition to this valve. The MultiBonnet is standard on this valve.

8555DL

APPLICATION

These multivalves permit liquid withdrawal from DOT cylinders with up to 100 lbs. propane capacity. They eliminate unnecessary cylinder handling when serving high volume loads and allow on-site filling into vapor space without interrupting gas service.

8555D AND 8555R SERIES

APPLICATION

These multivalves permit vapor withdrawal from DOT cylinders with up to 200 lbs. propane capacity. They allow on-site cylinder filling without interrupting gas service.

6532, 6533, 6542 AND 6543 SERIES

APPLICATION

These multivalves permit vapor withdrawal from ASME containers up to 50 sq. ft. surface area and DOT containers up to 420 lbs. propane capacity. They allow on-site cylinder filling without interrupting gas service.

7556P

APPLICATION

These compact multivalves are especially suited for vapor withdrawal of ASME containers where compact groupings of components are necessary. Separate filler valves and pressure relief valves are required.
